LED advertising machine series

LED vertical advertising machine

Product Features:1. Fashion: Elegant and fashionable shell, multi-color matching, can be perfectly integrated into the use environment. Various styles, users can choose different models according to different environmental characteristics;2. Highlight: all-weather clearly visible brightness up to 3700nit;3. Sensitivity: It supports the screen brightness to change according to the changes of the external brightness, which has the effect of power saving and comfortable display;4. Backlight: Support 10 groups of time period timing backlight control, play a power saving and comfortable display effect;5. Temperature control: The intelligent temperature control system maintains a constant temperature and dry environment inside the fuselage to prevent fogging and condensation;6. Explosion-proof: the shell is made of cold-rolled plate or stainless steel, and has been treated with paint, waterproof, sun-proof and explosion-proof professional surface technology;7. Anti-reflection: The front of the product adopts imported anti-glare glass, which can effectively increase the internal light projection and reduce the reflection of external light, making the LCD screen display the image color more vivid and bright;8. Timing: The product supports 7 working days X16 group timing switch, which effectively replaces the switching power supply of personnel on-site;9. Waterproof: The entire confidentiality is designed to prevent outside dust and water from entering the interior, reaching the IP65 standard;10. Code: Using professional hardware decoding chip, it can smoothly support a variety of formats SD and HD video and image decoding playback, up to 1920*1080P HD video playback 1920*1080 resolution HD image decoding;11. System: Built-in embedded ucLinux operating system and professional combined playback software, automatic operation, automatic management, no poisoning, no crash;12. Out: Through the reliable hard disk self-check and repair mechanism, the player supports more than 10,000 forced power-off and switch-off without damaging the file, and reliable broadcast;13. Use: The player does not need to be maintained by specialized network personnel, the player can automatically run after startup, automatically shut down, self-management, and easy to use;14. Change: Support multiple groups of machines to play pictures synchronized switching, you can add any switching effect.
    LED广告机主要技术参数()
    物理点间距2.5mm
    单元板尺寸160X160mm
    产品尺寸480×1920(mm)
    物理密度 160000点/㎡
    发光点颜色 1R1G1B
    单元板分辨率 64*64=4096 DOTS
    单元板重量0.24kg
    箱体分辨率256*256
    箱体面积0.4096m²
    压铸铝重量10.78KG±0.05KG
    主要技术参数
    最佳视距2m~30m
    可视角度水平≧160°可选
    垂直≥160°可选
    平均功耗<600W/㎡
    最大功耗<1200w/㎡
    控制方式:同步控制
    显示卡 DVI显卡
    驱动方式 1/32扫描
    最大功率 ≤18W
    换帧频率≧360Hz
    白平衡亮度 ≧1000cd/㎡
    刷新频率 ≧1920Hz
    亮度调节方式
    驱动IC:ICN2038
    16级可调
    软件手动调节:100级可调100
    计算机操作系统
    WIN98、WINXP、WIN2000,etc
    视屏信号
    RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION等
    控制系统
    PCTV卡(可选optional)+DVI显卡+主控卡+光纤传输(可选optional)
    平均无故障时间 ≧5000小时
    寿命 75000~100000小时
    像素失控率  <0.0002件
    项目分类 PH2.5-32S
    封装形式 三合一
    LED封装方式 2121
