Led transparent screen series

Ph3.91-7.82 transparent screen

More than 80% of the perspective effect of the high transparency effect makes the glass retain the function of daylighting and perspective, and the existence of LED lights can hardly be seen from a long distance, so that the space near the sightseeing elevator is not affected. Lamp mounting design lamp bead concave PCB board not only has the function of mask protection, but also can improve the stability of the patch to prevent the lamp from dying, and the playback effect is more stable. The appearance is neat and exquisite, and the power wiring is built-in, which makes the whole screen look beautiful and generous. The advantages and features of the new LED sightseeing elevator screen are convenient and fast indoor maintenance, which is fast and safe, saving manpower and material resources.To save the lighting cost of the building, if the LED sightseeing elevator screen is installed, a large part of the lighting lamps on the external wall can be saved. At the same time, the LED screen is more absorbing, which can save the cost and benefit the advertising. Energy saving and environmental protection do not need traditional refrigeration system and air conditioning cooling. Easy to operate through the network cable or computer, or video card, or remote transceiver, change the display content at any time. The product can be used in a wide range of applications as long as there is a place for sightseeing elevator. Such as shopping malls, theaters, commercial streets, hotels, municipal public buildings, landmark buildings and so on.

    PH3.91-7.82 室内透明全彩屏技术参数

    屏体参数

    Screen Specification



    说明

    Instruction

    技 术 指 标 参 数

    Technology Index Parameters









    像素管单元箱

    Single Cabinet

    1)物理点间距:横 3.91-竖 7.82mm

    1) Pixel:3.91-7.82mm

    2)物 理 密 度:32768 点/m2

    2) Density: 32768dot/m2

    3) 发光点颜色:1R1G1B

    3) LED Composition: 1R1G1B 4)基 色:纯红+纯绿+纯蓝

    4) Color: Pure Red + Pure Green + Pure Blue















    显示屏整屏

    Whole Screen

    1)最 佳 视 距:5~180m

    1) Best Viewing Distance:5-180m

    2)最 佳 视 角:水平 120 度,垂直 120 度

    2) Best Viewing Angle: horizontal:120. Vertical: 120

    3)环 境 温 度:存贮 -40℃ ~ +85℃,工作 -20℃ ~ +60℃

    3) Environment Temperature: Storage: -40 +85℃,

    Working: -20℃ ~ +60℃ 4 相 对 湿 度 :10%~95% 4Humidity:    10%95% 5) 屏 体 厚 度 :8cm 5Screen Depth: 8cm







    供电

    Power

    1 工 作 电 压 :100-220V 1Working  Voltage:   100-220v 2 平 均 功 耗 :350W/m2 2Average Consumption: 200W/m2 3最 大 功耗:≤800W/m2

    3Max Consumption: ≤800W/m2









    控制系统

    Control System

    1)控 制 主 机:联想开天主机或同档次计算机以上

    1) Control Computer: Lenovo 2)操 作 系 统:WIN 7/ 8 / XP

    2) Operation System: WIN 7 / 8 / XP 3控 制 方 式:同步控制3Control Waysynchronization

    4)显 卡:DVI 显卡

    4Display Card: DVI display card
